PRODUCT DESCRIPTION2.
1
Worktop
2
Detergent/Softener Dispenser
3
Control Panel
4
Door Handle
5
Door
13
Rating Label
14
Drum Leaf Lifter
7
6
Level Adjustment Feet (Front)
8
Mains Cable
9
Water Inlet Hose
10
Water Drain Hose
11
Hose Support (2pcs)
12
Back Feet (Fixed)
Transit Bolts (3pcs)
6 www.electrolux.com
To connect the drain
hose on the edge of a
sink.
Plastic caps
To close the holes on
the rear side of the
cabinet after the
removal of the transit
bolts.
ACCESSORIES
Plastic hose guide
3
4
5
7
2
1
12
6
9
8
13
14
11
10
This machine is integrated drain design; lint will be drained out and don't need to clean the
filter regularly. If you would like to clean the filter, please contact your local Service
Center.
*
