CONTROL PANEL3.
Program Selector Knob
Spin Selection Touchpad
On/Off Button
Temperature Selection Touchpad
5
6
7
8
Sensor Wash Touchpad
Start/Pause and
Add Clothes Touchpad
Prewash Touchpad
11
Display
12
Save Favourite Program Option
13
Child Lock Option
Vapour Touchpad
9
10
Delay End Touchpad
Time Manager Touchpad
3.1 Control Panel Description
9
3 75
A)
B)
C)
D)
Program Time
Time Manager Level
Add Clothes Icon
Program Phase Indication Icon:
421 6
12 13
8
11 10
F
E
D
B
A
C
Ultramix phase
Wash phase
Rinse phase
Spin phase
Vapour phase
Anticrease Phase Icon
Prewash
Vapour
SensorWash™
