Worktop
Drum Lifter (X3)
Drain Pump
Filter Door
2.2 Accessories
To connect the drain hose
on the edge of a sink.
To close the holes on
the rear side of the
cabinet after the
removal of the transit
bolts.
Plastic Caps
Plastic Hose Guide
A
Detergent/Softener Dispenser (see page 18)
B
Cabinet
C
Front Panel
D
Control Panel (see page 10)
E
Door
F
Drain Pump Filter (see page 26)
G
Level Adjustment Feet - Front
H
Transit Bolt
I
Water Inlet Hose (see page 37)
J
Transit Bolts & Hose Support
K
Mains Cable
L
Water Drain Hose (see page 38)
M
Level Adjustment Feet - Back
N
Compartment: Softener
Compartment: Prewash
Compartment: Main Wash
Stainless Steel
Washing Drum
Drain Pump
Filter
Transit bolts must be removed
before using the appliance.
Transit bolts must be removed
before using the appliance.
