4
Temperature touch button
(Temperatura)
5
Display
6
Drying time touch button (Tiempo/
Tempo de sec.)
7
Delay start touch button ( Inicio
Diferido)
8
Prewash touch button (Prelava.)
9
Drying level touch button (Nivel
de sec.)
10
Start/Pause touch button (Inicio/
Pausa)
11
Time Manager touch button
(Time Manager)
4.2 Display
A B C
D
E
F
GH
I
J
K
A. The Temperature area:
: Temperature indicator
: Cold water indicator
B. : Time Manager indicator.
C. The time area:
•
: the programme duration
• : the delay start
• : the alarm codes
• : the message of error
•
: the programme is completed.
D. : The drying phase.
E. : The steam phase.
F. : The permanent Extra rinse
option.
G. , , : The indicators of dryness
level.
H. The spin area:
• : the Spin speed indicator
• : the No spin indicator
• : the Rinse hold indicator
I.
: The washing phase.
J. : The child safety lock indicator.
K. : The door locked indicator
