TECHNICAL DATA13.
Dimensions (Height / Width / Depth)
Maximum dry
clothes capacity
Spin speed (Maximum / Minimum) 1200 rpm / 400 rpm
Power supply (Voltage / Frequency)
Total power absorbed
Water supply pressure (Maximum / Minimum)
0.8 MPa / 0.05 MPa
Minimum fuse protection 10 A
Max.
1)
4 kg
4 kg
3 kg
4 kg
Max.
1)
–
Max.
1)
Max.
1)
1.5 kg
1.5 kg
4 kg
Max.
1)
1 kg
–
WashingProgram
Max.
1)
3 kg
–
–
–
Max.
1)
–
Max.
1)
Max.
1)
1 kg
–
–
4 kg
1 kg
–
Drying
1) Maximum capacity depended on the model of the Washer Dryer (see defined
on the control panel).
Cottons
Mixed
Delicates
Bedding
Sports
Energy Saver
Tub Clean
Spin
Rinse + Spin
Wool
Quick 15
Daily 39
Full Wash 60
WashDry 60
Favourite
INSTALLATION14.
14.1 Unpacking
85 X 60 X 57.5 cm
220 - 240 V~ / 50 Hz
Wash: 2000 W / Dry: 1100 W
You are advised to keep all transit
devices so that they can be refitted if the
machine ever has to be transported
again.
All transit bolts and packing must be
removed before using the appliance.
CAUTION!
Use gloves. Remove the external film.
If necessary, use a cutter.
1.
6.
7.
Remove the polystyrene base.
8.
Put one of the polystyrene packaging
elements on the floor behind the
appliance. Carefully put down the
appliance with the rear side on it.
Make sure not to damage the hoses.
Pull up the appliance in vertical
position.
Open the door. Remove all the items
from the drum.
5.
9.
Remove the power supply cable and
the drain and inlet hoses from the
hose holders (A) on the rear of the
appliance.
Remove the cardboard top.
2.
Remove the polystyrene packaging
materials.
3.
Remove the plastic bag which cover
the machine.
4.
