2.2 Cassette Type
TEMP
AUTO
COOL
DRY
HEAT
FAN
HIGH
LOW
MODE
FAN SPEED
VERTICAL/
SWING
TIMER ON
SLEEP
ON/OFF
TIMER OFF
RESET LOCK
SET TEMPERATURE( C)
FOLLOW
ME
TURBO
HORIZONTAL/
SWING
MED
2
3
9
11
1
4
6
5 7 8
11
12
10
1 Air flow louver (at air outlet)
2 Drain pump (drain water from indoor unit)
3 Drain pipe (optional)
4 Air outlet
5 Air lter(inside air-in grill)
6 Air inlet
7 Air-in grill
8 Display panel
9 Refrigerant pipe (optional)
10 Remote controller
11 Air inlet
12 Air outlet
