Electrolux GK58TSO - Installation Diagrams and Dimensions

ON-TOP INSTALLATION
1.
R 5mm
min.
55mm
560
+1
mm
490
+1
mm
2.
3.
min.
28 mm
4.
min.
12 mm
min.
20 mm
INTEGRATED INSTALLATION
1.
516
+1
mm
560
+1
mm
490
+1
mm
586
+1
mm
R10 mm
R5 mm
13 mm
8 mm
min.55mm
2.
min.
28 mm
