Step 1 Fully open the door and find the
hinge to the right side of the
door.
Step 2 Use a screwdriver to lift and turn
fully the right side hinge lever.
Step 3 Find the hinge to the left side of
the door.
Step 4 Lift and turn the lever fully on the
left hinge.
Step 5 Close the oven door halfway to
the first opening position. Then
lift and pull forward and remove
the door from its seat.
Step 6 Put the door on a soft cloth on a
stable surface.
Step 7 Hold the door trim (B) on the top
edge of the door at the two sides
and push inwards to release the
clip seal.
Step 8 Pull the door trim to the front to
remove it.
Step 9 Hold the door glass panels by
their top edge and carefully pull
them out one by one. Start from
the top panel. Make sure the
glass slides out of the supports
completely.
ENGLISH 37
