ENGLISH -

OPERATION

ENGINE ADJUSTMENTS (Fig.KI)

Refer to the engine manufacturer’s maintenance ma-

nual.

CAUTION:- 0.6l Oil must be added to the

engine before use

STARTING THE ENGINE (Fig.K

II)

Once the machine has been set up properly, start the

engine as follows:

a) Engines with choke system:

when the engine is cold, position the accelerator lever

(Fig.K

III - pos.13) on START

b)Operate the engine stop lever (14) to prepare the

engine for start, keep lever pressed against handle

while starting and using the machine (it operates the

engine brake).

c) Engines with primer system:

Press the fuel-enrichment pump (23) located on the

carburettor 3 or 4 times position the accelerator lever

(13) on MAX.

For further information and explanations, read carefully

the user instruction manual of the engine.

d) Start engine.

MANUAL STARTING: (While holding the engine stop

lever (14)).

 Hold the engine start-grip (11) and pull the starter rope

gently until you feel the resistance caused by compres-

sion. Return the starter rope slowly then pull the handle

firmly towards you to its full extent.

ELECTRICAL STARTING: (While holding the engine

stop lever (14)).

 Insert the plug (G) in the socket (H) on the engine.

Turn the ignition key (17) or push the button (25) ,only

for the models with this equipment

CAUTION: The blade starts turning as soon

as the engine is started.

Keep the engine stop lever (14) depressed during machine

operation. When the lever is released, the engine stops.

When leaving the machine for any period of time always

remove the push button (25).

Remove the push button by turning until the key and

keyway line up, and then pull out.

Fit in reverse order

MOWING (Fig.K

III)

To cut the grass, push the lawn mower manually or insert

the automatic advance gear.

Before proceeding with the coupling of the automatic feed,

choose the speed by means of the change lever (20) (for

the models where it is included only).

Change the speed with the clutch disengaged.

There are 3 speed settings.

1°~ 0,6 m/s

2°~ 0,9 m/s

3°~ 1,2m/s

How to insert automatic advance: Lift up the clutch

handle (18) and keep it pressed in position.

CAUTION: Engage the gear only when the

engine is running.

How to disengage advance: Release the clutch han-

dle.

VERSION AUTO THROTTLE (Fig.K

IV)

- The Automatic throttle increases the engine speed to

maximum when you engage the self drive.

- This is to ensure you have maximum engine speed

when you mow but a lower speed and quieter when

not mowing. It also provides a soft start to the self drive

mode.

- In order to mow in the push mode but at maximum en-

gine speed - then you can fit the override lever which is

supplied with the product.

You should only fit this lever if you wish to override the

Automatic

throttle system and have maximum engine speed when

in the push mode and the drive mode.

- Fit the lever to the side of the handle as shown so that

when the lever is pushed forward the throttle cable is

tightened and the throttle is at maximum.

VERSION WITH BLADE BRAKE (Fig.K

With engine running, pull the handle (14) towards the bar

and keep depressed. Push the blade engagement lever

(19) forward to make the blade rotate.

WARNING! When the handle (14) is released

the blade stops while the motor continues

running.

MOWING
