1 - BAR
2 - CHAIN
3 - FUEL TANK CAP
4 - OIL TANK CAP
5 - STOP SWITCH
6 - STARTER HOUSING
7 - STARTER HANDLE
8 - FRONT HANDLE
9 - AIR FILTER COVER
10 - CHOKE KNOB
11 - CARBURETOR ADJUSTMENT SCREWS
12 - SAFETY CHAIN BRAKE
13 - BAR RETAINING NUTS
14 - CHAIN CATCHER
15 - MUFFLER SHIELD
16 - REAR HANDLE
17 - THROTTLE TRIGGER LOCKOUT
18 - THROTTLE TRIGGER
19 - CHAIN BRAKE COVER
20 - CHAIN ADJUSTER SCREW / INTENZ
21 - SPIKE/SPACER
22 - THROTTLE ADVANCE
23 - DECOMPRESSION VALVE
ENGLISH - 1
A. General description
If not used properly this chainsaw can be dangerous.
The warnings and safety instructions must be followed to ensure reasonable
safety and efficiency in using this product. The operator is responsible for
following the warnings and instructions in this manual and on the product.
Safety precautions
Explanation of Symbols
Read operator’s manual carefully
Wear safety clothing:
Approved safety glasses or face shield
Approved safety helmet
Approved ear defender
Approved gloves
Approved safety footwear
Always have a first aid kit nearby
Noise emission to the environment
according to the European
Community’s Directive.
This product is in accordance with
applicable EC directives.
Do not smoke while refuelling
or while operating the machine
Warning - Caution
Choke fully opened (hot start /run)
To Next Page
