2:1
438 9142-61/04
5325
2
5326
3
5327A
1
Installation
Transportation and unpacking,
W365H, W375H, W3105H
The machine is delivered complete with expan-
sion bolts etc. packed inside the machine in the
drum.
The machine is delivered bolted onto the trans-
port pallet and packed in a crate or box.
• Remove packing from the machine.
• Remove front panel. Remove the bolts bet
-
ween the machine and pallet.
• Mount front panel.
When the machine is lifted off the pallet: Make
sure that the machine does not come down on
the floor with either of the rear corners first. The
side panel of the machine can be damaged.
• Mount the feet.
• Place the machine on its final position.
• Level the machine with the feet of the machi
-
ne.
The machine also comes with transport safety
devices (four plate angles between the support
and the drum).
In order to remove the safety devices:
• Remove front and rear panel.
• Remove both front metal angels.
• Remove both rear metal angels.
• The machine may not be moved with the
transport securities removed. Save the trans-
port securities for future use.
Fig.
1
Fig.
2
Fig.
3
