ETOR-55
ETF-744/99
sensor’s wire
sensor’s wire
sensor’s wire
(not included in the set)
heating cable
Single-phase electric circuit
Connection diagram of ETO2-4550 controller
with ETOR-55, ETF-744/99 and ETOG-56T sensors.
Protection of roof edges, gutters, downpipes
and external surfaces – two zones.
single-phase
circuit
ETOG-56T
+
ETOK-T
L
PE
N
PE
L
L'
L'
L
L
PE
brown
brown
green
green
yellow
white
grey
pink
yellow
white
18
heating cable
Sensors for controllers
ETO2-4550 & ETR2-1550
