Element RC Utron SE - Chassis Shock Mounts and Rear Axle Assembly; Gate 14: Final Chassis Shock Mounts; Rear Axle Housing and Components

CHASSIS BUILD:
GATE 14
REAR AXLE BUILD:
REAR AXLE BUILD:
GATE 02
GATE 01
11
33.657120, -117.701139
NOTE: Install left and
right side drive shafts
NOTE: Install left and right side
axle mounts and wheel hexes
x1
42321
5x10x4mm
Bushing
x1
42310
Brake
Rotor
x1
42019
Pin,
2x11mm
x1
x2
42068
Drive Shaft,
Rear
25201
3x8mm
FHCS
x1
42308
Lower 4-Link
Mount
x2
71032
2.5x14mm
SHCS
91560
5x10x4mm
Bearing
x1
42310
Wheel Hex,
6mm
42076
FT Enduro
Wheel Hexes,
6 mm, steel
x1
x1
x1
42307
Axle Housing,
Rear
42335
Pinion Gear,
8T
42308
Axle Housing
Diff Cover
x2
x2
x2
42321
5x12x4mm
Bushing
4673
2.5x4mm
BHCS
91479
7x14x3.5mm
Bearing
91567
5x12x4mm
Bearing
x1
42335
Ring Gear,
30T
x2
42321
5x10x4mm
Bushing
91560
5x10x4mm
Bearing
x4
41086
2.5x16mm
SHCS
BLACK GREASE
#6588
x1
x1
42304
Shock Mount
(Left, Rear)
42304
Shock Mount
(Left, Front)
x4
25203
3x12mm
FHCS
42336
FT Ring/Pinion
Option
