SHOCK BUILD:
GATE 04
BUMPER BUILD:
GATE 01
BUMPER BUILD
GATE 02
14
x2
x2
x1
x1
2308
3x18mm
BHCS
89203
3x16mm
BHCS
42353
Front
Bumper
42353
Rear
Bumper
x1
x1
x1
x1
x1
x1
x1
x1
x1
x1
42041
Pivot Ball
4689
3x16mm
Set Screw
42041
Pivot Ball
42308
5mm Shim
25215
M3
Locknut
91478
3x30mm
BHCS
89203
3x16mm
BHCS
42041
Pivot Ball,
Upper Shock
42041
Pivot Ball,
Upper Shock
89203
3x16mm
BHCS
