QUICK START GUIDE
5
Wall Mounting
The TV is provided with mounting holes for a VESA approved wall mounting bracket (not supplied). To install remove screws,
holding the base to the base bracket and lift the base away (do not remove the base mounting brackets). Mount the VESA bracket
using 4*M6*12 isometric threaded screws (not supplied).
3. When finished lift TV up and place it on a stable flat surface.
*It is recommended that two people take part in the base stand installation
1. Remove any plastic wrapping from the TV and stand. Place the TV
screen-down on a clean and flat surface to prevent scratches or
damage to the screen.
2. Connect the TV and the legs as pictured and using the four screws
provided. With a Phillips screw driver, screw each leg into place.
INSTALLING THE BASE
