Safety
Residual heat indicators
After using the cooktop, waste heat remains in the heating area. The
power nixie tube shows the code “H”, warning to be away from the
heating area.
Auto shut down protection
During the cooktop working, it shut off automatically when the default
timing reach by the program if without operating. If several heating
zones work simultaneously, the cooktop will be automatically shut of f when
anyone heating area reaches it’s default timer. The default working
timer for various power levels are shown in the table below:
Installation
Selection of installation equipment
Drill holes on the table surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 50 mm space shall
be preserved around the hole.
Be sure the thickness of the table surface is at least 30mm. Please select
heat-resistant table material to avoid larger deformation caused by the heat
radiation from the cooktop.
As shown in Figure (1)
Power level 1 2 3 4 5 6 7 8 9
Default working
time(hour)
8 8 8 4 4 4 2 2 2
50mm mini
50mm mini
50mm mini
50mm mini
560mm
490mm
