8
INSTRUCTION ON MOUNTING AND USE
GB
fix with two rods.
Attention! The rods are included in the carbon filter
packing and not on the hood.
To dismantle the filter act in the reverse manner.
Replacing lamps - Fig. 4
Firstly check that the lamps are well cooled prior to replacing
them.
Use a small screwdriver as a lever on the borders of the
lamp in order to remove the lightbulb.
Unthread the connector G.
Slide out the lightbulb to be replaced and replace with a new
12V 20W 30° Ø35 12V GU4 PHILIPS STANDARD LINE code
425409.
Carry out the replacement and mount the new lightbulb by
following instructions in the reverse.
If the lights do not work, make sure that the lamps are
fitted properly into their housings before you call for
technical assistance.
Caution
This appliance is designed to be operated by adults. Children
should not be allowed to tamper with the controls or play with
the appliance.
Do not use the cooker hood where the grill is not correctly
fixed! The suctioned air must not be conveyed in the same
channel used for fumes discharged by appliances powered
by other than electricity. The environment must always be
adequately aerated when the cooker hood and other
appliances powered by other than electricity are used at the
same time. Flambé cooking with a cooker hood is
prohibited. The use of a free flame is damaging to the filters
and may cause fire accidents, therefore free flame cooking
must be avoided. Frying of foods must be kept under close
control in order to avoid overheated oil catching fire. Carry
out fumes discharging in accordance with the regulations in
force by local laws for safety and technical restrictions.
Installation - Fig. 5
Consult the designs in the front pages referenced in the text
by alphabet letters. Closely follow the instructions set
out in this manual. All responsibility, for any eventual
inconveniences, damages or fires caused by not complying
with the instructions in this manual, is declined.
The hood must be at a distance of not less than 30 cm from
the cooking top with electric plates.
The hood is supplied in the FILTERING version and is used
without an extracted fumes discharger conduit .
Fumes and steam are recycled through the F deflector (11F).
If you intend using the product in the SUCTION version, it
is necessary to have an evacuation conduit going from the
upper B exit to the extraction hole towards the exterior.
In this case a connection ring (11A) has to be installed on
the B extraction hole and the carbon filter removed.
A telescopic flue is available (as an accessory).
Preliminary information for installation of the hood
Expansion wall plugs are provided to secure the hood to
most types of walls/ceilings. However, a qualified technician
must verify suitability of the materials in accordance with the
type of wall/ceiling. The wall/ceiling must be strong enough
to take the weight of the hood.
Do not tile, grout or silicone this appliance to the wall.
Surface mounting only.
Only for some models
An aesthetic flue can be purchased as an optional accessory.
Check with the assistance centre whether the model in your
possession envisages this possibility.
We advise installing the hood after having purchased the flue
to check with certainty the most suitable installation.
During electrical connection ensure the power supply is
disconnected at the domestic main switch.
Apply three adhesive strips C to the back of the hood.
If necessary (in the case of walls not perfectly
perpendicular or in the presence of walls partly covered
with tiles) apply two D spacers in correspondence with
the definitive fixing holes (click fixing).
Trace a centre line on the wall to facilitate the montage
(1), position the hole template so that the middle line
printed on it corresponds to the centre line previously
drawn and that the lower side of the grill corresponds to
the lower part of the hood once mounted (2).
Make two holes with the 8 mm Ø drill and fix the support
bracket with two dowels and wall screws (3).
Open the steam screen and remove the grease filter (see
relative paragraph).
Hang up the hood (4), adjusting its position (5-6) and from
the inner part of the hood mark two points for the definitive
fixing (7). Remove the hood and make two 8 mm Ø holes
(8), insert two wall dowels, hang the hood up again and
fix it definitively with two screws (9).
Connect the electricity (10), but leave the hood
