7INSTRUCTION ON MOUNTING AND USEGB
Description of the hood - Fig. 1
1 Control panel
2 Grease filter
3 Grease filter release handle
4 Halogen lamp
5 Vapour screen
6 Air outlet
7 Telescopic flue (optional)
Operation
To select the functions of the hood just touch the commands.
Light key ON/OFF
Intensive speed selection key (suction power) -
duration 5 minutes - press again to return to previous
setting.
High-speed selection key (suction power).
Medium-speed selection key (suction power) -
when flashing it indicates the need to wash or replace
the carbon filter. This signal is normally deactivated.
Press keys 1 and 2 at the same time to activate it. At
first only key 1 will flash and then both keys 1 and 2
to indicate activation. Repeat the operation to deactivate
the signal. At first keys 1 and 2 will flash and then only
key 1 to indicate deactivation.
Low-speed selection key (suction power) when
flashing it indicates the need to wash the fats filter.
Motor key OFF (stand by) excludes the electronics
reset wash/replace filters signals.
MOTOR OFF
Press briefly to switch the motor off.
RESET FILTERS SIGNALS
After having carried out maintenance of the filters,
press the key for 3 seconds. Flashing led 1 (fats filter)
or 2 (carbon filter) will stop flashing.
EXCLUDING THE ELECTRONICS
Press the key for 3 seconds. The hood command
electronics will be excluded.
This function can be useful during the product cleaning
operations.
Just repeat the operation to reinsert the electronics.
Use the high suction speed in cases of concentrated kitchen
vapours. It is recommended that the cooker hood suction
is switched on for 5 minutes prior to cooking and to leave
in operation during cooking and for another 15 minutes
approximately after terminating cooking.
The steam screen must always be left closed and opened
only for maintenance (e.g. cleaning or changing filters).
If the hood fails to operate correctly, briefly disconnect it from
the mains power supply for almost 5 sec. by pulling out the
plug. Then plug it in again and try once more before
contacting the Technical Assistance Service.
Maintenance
Prior to any maintenance operation ensure that the cooker
hood is disconnected from the power supply.
Cleaning
The cooker hood should be cleaned regularly internally and
externally.
For cleaning use a cloth moistened with denatured alcohol
or neutral liquid detergents. Avoid abrasive detergents.
Warning:
Failure to carry out the basic standards of the cleaning of the
cooker hood and replacement of the filters may cause fire
risks.
Therefore we recommend oserving these instructions.
Steam screen
The steam screen must always be left closed and opened
only for maintenance (e.g. cleaning or changing filters).
Opening the steam screen:
Press the lower part of the steam screen firmly. After
coupling, accompany it upward.
Closing the steam screen:
Accompany the steam screen downwards, press firmly
and check the resulting coupling.
Grease filter
This must be cleaned once a month using non aggressive
detergents, either by hand or in the dish-washer, which must
be set to a low temperature and a short cycle.
When washed in a dish-washer, the grease filter may
discolour slightly, but this does not affect its filtering capacity.
Removing the grease filters - Fig. 2
Open the steam screen.
Pull the handle downwards and extract the filter.
Charcoal filter (filter version only)
It absorbs unpleasant odours caused by cooking.
The charcoal filter can be washed once every two months
using hot water and a suitable detergent, or in a dish-washer
at 65°C (if the dish-washer is used, select the full cycle
function and leave dishes out).
Eliminate excess water without damaging the filter, then
remove the mattress located inside the plastic frame and put
it in the oven for 10 minutes at 100° C to dry completely.
Replace the mattress every 3 years and when the cloth is
damaged.
Montage - Fig. 3
Open the steam screen and remove the grease filter.
Install the carbon filter on the back of the grease filter and
