[baud] digit
0 4800 0 Electronica
1 1200 1 КА ORGTECHNICA
2 2400 2 КА Еlka 752, Datecs
3 4800 3 КА Karat, Deisy, Bimco scales
4 9600 4,5 КА Eltrade
5 19200 6
Protocol with continuous
dispatching of the weight
6 38400 7,8 Connection with PC, PRN
7 4800 9 Scales Angel, CAS, DIBAL
For example: CASH 02 means speed 4800 for cash register Е752 or Datecs.
When connecting to cash register, the scales sends inquiry for weight through the interface
but is can send data for the balanced load by operator’s order by pressing PRN .
Note: The connection with PC and label printers is managed by set speed and protocol 7, For
example: In mode CASH47.
* The software and cables for connection are additionally offered by the manufacturer.
8.6. Error Mode
The error mode is shown by lighted bottom segments (lines) along the display and a sound
signal.
The Error Mode is indicated when:
- The scale is overloaded. On the scale’s plate is marked the maximal load – the
sum of the tare and the goods weighed shouldn’t exceed the maximal load.
If the scale is overloaded, remove the load from the platter.
- The scale reads a mass below the Zero. Adjust the metal platter – the rubber
tampons should go into the corresponding holes of the aluminum load-
transmitting body and press >0< to zero the scale.
- When turning the scale on ON/OFF , after all self-checks are completed the
scale reads out a large diversion from the Zero position set by the manufacturer.
Remove all loads from the platter; make sure that the platter is placed properly. If
necessary press the >0< key.
