8
The IR receiver will be connected from the screen
IR “eye” sensor
11.65 mm. in width
Power cord
A
rox. 6 ft. len
th.
Although the IR remote requires a direct line of sight with the IR sensor to
function, the screen’s case can be hidden from sight and operated using the
RF remote. When depressing the directional buttons you should hear a faint
click signifying that the mechanism is working properly.
80mm in width
UP
Stop
Down
IR RF
This is the IR (Infra-Red) remote with a
range of 15 Ft. Battery size AAA
This is the RF (Radio Frequency) remote
with a range of 30 Ft. Battery size AAA
** Please remember to always point to the wall switch receiver when using the IR remote. The IR remote can also work
with a Universal Learning Remote Control usually by programming the Screens IR codes into your Universal Learning
Remote.
