Elite 626 - Machine Components

18
MACHINE COMPONENTS
1. Control lever for loading
the capsules
4. Dispensing
spout
5. Drip tray grid
6. Drip tray with capsule container
(extractable)
8. Water tank
(extractable)
11. Main switch
9. Plug
7. P
ower cable
10. Small cup support
3. Big cup
2. Small cup
11
. Main switch
