17
GB
ENGLISH
3) To position the front roller in the correct posi-
tion, remove the 4 lower elastics (Fig.4).
4) Slacken the drive belt by making it come off the
respective front and rear guides (Fig.5 and 6)
5) Undo, but not completely (max. 3-4 complete
turns,) the front support fixing screws (Fig.7 and
8), using the hex key supplied.
6) Repeat the same operation on the opposite side
(Fig.9 and 10)
7) After releasing the mechanism, move the
roller back or forward as required. This opera-
tion must be carried out by lifting the roller just
enough in order to pass each single seat
(Fig.11).
4
5
7
6
8
9
10
11
