Elite Amplier Owner’s Manual
SUBWOOFER CHANNEL
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >100dB
Low Pass Crossover: 24dB per Octave
Subsonic Filter: 24dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 1 ohm
Typical Eciency: 85%
Damping Factor: Greater than 200
RMS Power 14.4Vdc ≤ 1% THD 700 x 1 @ 2 ohms
1100 x 1 @ 1 ohm
SPECIFICATIONS
FRONT AND REAR CHANNELS
Frequency Response: ± 1dB from 20Hz to 50kHz
Signal to Noise Ratio: >110dB
High and Low Pass Crossovers: 18dB per Octave
Front/Rear High Pass Crossover Range: 20Hz to 4kHz
Rear Low Pass Crossover Range: 40Hz to 4kHz
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 4 ohms Bridged or 2 ohms Stereo
Typical Eciency: 55%
Damping Factor Greater than 200
RMS Power 14.4Vdc ≤1% THD 100 x 4 @ 4 ohms Stereo
150 x 4 @ 2 ohms Stereo
300 x 2 @ 4 ohms Bridged
Recommended Fuse Size: 150 amp
Power/Ground Wire Size: 1/0 Gauge
Dimensions: 23.3” L x 10.5” W x 2.6” H
592mm L x 267mm W x 66mm H
A NOTE ABOUT SPECIFICATIONS....
Elite ampliers were engineered to be the best sounding mobile ampliers on the
planet. Numbers on this sheet of paper can not truly convey the dynamics and
realism these ampliers can deliver. Enjoy !
Note: A power birth certicate is included for each amplier. Elite
ampliers are VERY CONSERVATIVELY rated and will exceed the
RMS power rating by up to 30%.
