Elmo 16-CL - Page 33

P. TRANSFORMER
Disassembly
(i)
Remove Fig. 1'"10,23,18,15 .
(2)
Remove Fig. 15-6,5*
(3)
Disconnect lead wires of Fig.
15-3.
(4)
Remove Fig. 15-3 by detaching
Fig.
15-1x4
(5)
Remove Fig. 15-4 by detaching
Fig.
15 - 2 x 2
2. Assembly
Follow the reverse way of the above steps, paying attention to the
following point.
(l) Adjust the tension of Fig. 15-5*
