Physical connection must be afforded using a cable according to the diagram below:
WARNING
In the case of several units connected in a daisy chain,
the 100 Ohm termination must be placed on the last unit
1.0 OVERVIEW
Thank you for buying this product.
Check the contents of the packaging carefully. It contains:
18
3
TZ09 8X8+1 VIDEO AND AUDIO MATRIX
ELPRO BROADCAST s.r.l.
Strada della Pronda 17 - TORINO (ITALY)
Tel. 0117071955 - FAX 011706210
ELPRO BROADCAST s.r.l.
Strada della Pronda 17 - TORINO (ITALY)
Tel. 0117071955 - FAX 011706210
TZ09 8X8+1 VIDEO AND AUDIO MATRIX
The TZ09 is an 8X8 video and audio stereo matrix with fixed preview outputs.
A built-in loudspeaker permits immediate local audio monitoring.
A headphones output is also provided.
The characteristics of this unit such as the loop type video inputs, the
breakaway and the possibility of control using a computer via RS232 make it
suitable for a range of both broadcasting and multi-media applications.
The ninth fixed preview output permits use of the matrix also as broadcasting
unit for TV studios.
The possibility of saving and recalling 8 configurations, via RS232, makes the
TZ09 highly versatile for presentations.
The TZ09 unit
- This handbook - The mains cable - The remote control
(optional)
