Serial number Description
1 Suction side connection point (1”)
2 Delivery side connection point (1”)
3 Outlet opening
4 Filling opening
5 Pump body
6 Pressure gauge
7 Pressure switch
8 Flexible pipe
9 Tank
10 Switchbox
11 Tank lling air valve
12 Rubber bag
The water supply apparatuses designated as „Automatic” are equipped with device of COELBO
Switchmatic 1 T-kit type. The device is an electric pressure switch, which has integrated
digital pressure gauge and dry-running protection as well. Find the detailed information about
the operation of the device in the additional manual attached (COELBO Switchmatic 1 T-kit
instructions for use).
INTENDED USE, FIELD OF APPLICATION
ATTENTION! This apparatus may be used only in households, for domestic purposes! The
VB domestic waterworks manufactured by ELPUMPS Ltd is suitable for supplying clean water or non aggressive liquids
having similar properties. It can be used excellently for supplying domestic water for households (irrigation, watering, animal
breeding), even from gas wells.
Use the pump exclusively in accordance with the technical data, within the framework of the application limits.
FIELDS OF APPLICATION
• Supplying clean water and other non corrosive liquids of low viscosity,
• Domestic water supply,
• Providing water for machines,
• Lifting water from drilled and dug wells,
• Garden irrigation,
• Irrigation of vegetable growing greenhouses, foil tents,
• Increasing the pressure in domestic water supply
Keep to the local regulations concerning the water supply. Contact a plumber. The device is suitable only for pumping the
following liquids:
GB
garden watering, water supply for automatic irrigation system, etc. It switches on an off automatically, in accordance with
the pressure values set. The water is emptied from the tank rst, and the pump does not switch on until the pressure
reaches the switch-on value. So you can take water without the pump switching on, thereby you can save energy.
