Product overview & technical specications
The MP LED Fresnel family are compact, robust and easy to use general purpose stage lighting xtures ideal for
small stages, studios and display lighting applications. These xtures provide a superb light output and benet
from temperature controlled fan cooling for whisper quiet operation. The 4 push button display allows users to
select DMX and manual dimming modes along with dimming curves.
• 1 x 75W quad-colour COB LED (RGBW)
• Manually adjustable beam angle: 10°- 50°
• 6031 Lux @ 2m (full on)
• 1.8kHz refresh rate
• DMX channels: 4/5 or 7 selectable
• 0-100% dimming
• 4 dimming curves in both LED and halogen proles:
Linear, square law, inverse square law and S-curve
• 4 push button menu with LCD display
• Captive power connection
• 3-Pin XLR input/output
• Filter frame and barn doors included
MP75 LED Fresnel RGBW
Specications MP75 LED Fresnel
Power consumption 86W
Power supply 100~240V, 50/60Hz
Dimensions 250 x 210 x 265mm
Weight 3.8kg
Order code ELUM105 - Black Housing
ELUM105A - White Housing
0m 2m 3m 4m 5m1m
50°
10°
10° - Lux
R
G
B
W
FULL ON
50° - Lux
R
G
B
W
FULL ON
4400
7640
1650
10800
24100
500
816
160
1110
2520
1104
1912
412
2694
6031
125
204
40
277
630
489
849
183
1200
2680
55
90
17
123
280
275
478
103
673
1510
31
51
10
69
158
176
306
65
430
965
20
32
6
44
101
210mm
250mm
230mm
210mm
350mm
265mm
