www.prolight.co.uk MP75 LED Fresnel RGBW User Manual
7
DMX mode:
Operating in a DMX control mode environment gives the user the greatest exibility when it comes
to customising or creating a show. In this mode you will be able to control each individual trait of the
xture and each xture independently.
To access the DMX address mode, press the “MENU” button on the front of the unit to show
“DMX ADDR” on the LCD display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons
to set the required DMX address. Press the “ENTER” button to conrm the setting.
To exit out of any of the above options, press the “MENU” button.
To access the DMX channel mode, press the “MENU” button on the front of the unit to show
“Channel” on the LCD display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to
choose one of the 4/5 or 7 DMX channel modes. Press the “ENTER” button to conrm the setting.
To exit out of any of the above options, press the “MENU” button.
Channel Value Function
1 000-100 Colour change (slow-fast)
101-200 Colour fade (slow-fast)
201-255 Sound active (sensitivity low-high)
2 000-255 Red (0-100%)
3 000-255 Green (0-100%)
4 000-255 Blue (0-100%)
5 000-255 White (0-100%)
6 000-030 Linear LED dimming curve
031-060 Linear Halogen dimming curve
061-090 Square LED dimming curve
091-120 Square Halogen dimming curve
121-150 Inverse Square LED dimming curve
151-180 Inverse Square Halogen dimming curve
181-210 S-curve LED dimming curve
211-255 S-curve Halogen dimming curve
7 000-255 Master dimmer (0-100%)
7 channel mode:
Channel Value Function
1 000-255 Red (0-100%)
2 000-255 Green (0-100%)
3 000-255 Blue (0-100%)
4 000-255 White (0-100%)
4 channel mode:
Channel Value Function
1 000-255 Red (0-100%)
2 000-255 Green (0-100%)
3 000-255 Blue (0-100%)
4 000-255 White (0-100%)
5 000-255 Master dimmer (0-100%)
5 channel mode:
Operating instructions
