D1
D2
W
H
81
© 2021, Elon Group AB. All rights reserved.
ERROR CODES
TECHNICAL INFORMATION
If there is a problem, the indicator lights will flash to help identify the error:
Codes Meaning Possible cause
The Rapid light
flashes rapidly
Long fill time. Tap is not open or water intake is restricted, or water pressure is too low.
The ECO light
flashes rapidly
Overflow. Overflow. There is a leak from the dishwasher.
WARNING
• If an overflow occurs, turn off the main water supply before calling for service.
• If there is water in the base of the dishwasher because of an overfill or small leak,
the water should be removed before restarting the dishwasher.
Height (H)
815 mm
Width (W) 448 mm
Depth (D1) 580 mm (with the door closed)
Depth (D2) 1150 mm (with the door opened 90°)
