Elvox Digibus 1284 User Manual

3
ALPHANUMERIC DISPLAY ENTRANCE PANELS: COMPONENTES
396
100
100
282
Art. 122N
Art. 123N
ADDITIONAL ENTRANCE PANELS
22
22
Art. 122D Art. 123D
Fig. 4
Fig. 5
Case width 88mm for 1 horizontal module and 50 mm depth.
Art. 9092
For 2 additional modules.
Height: 2 verical modules (248 mm)
Art. 9093
For 3 additional modules.
Height: 3 verical modules (360 mm)
FLUSH-MOUNTED BACK BOXES
HEIGHT OF 2-MODULE
ENTRANCE PANELS
HEIGHT OF 3-MODULE
ENTRANCE PANELS
