Service Info
Air Temp: The current temp in the living space.
Tank Temp: The temperature of the coolant inside the
Timberline tank.
Heater Temp: The coolant temp inside the Timberline heater.
Heat Exchanger: The temp of the domestic water
heat exchanger.
Circ Pump: Indicates if the circulation pump is activated
or not.
Solenoid: Indicates if the heating loop solenoid is activated.
Fuel Pump: Indicates if the Fuel pump for the Timberline
heater is activated.
Element Relay: Indicates if the 110V element is activated in
the Timberline Tank.
Service info
Air temp:
Tank temp:
Heater temp:
Heat exchanger:
Circ pump:
Solenoid:
Fuel pump:
Element relay:
62°F
61°F
65°F
63°F
No
No
No
No
