APPENDIX – Technical Data
Technical Data
Frequency response: <10 Hz - >200 kHz (-0.2 dB)
Low Band (Shelf Filter): 9 - 200 Hz (+/-15 dB)
Low Band (Cut Filter): 9 - 200 Hz
Bottom Band (Peak Filter): 18 - 400 Hz (+/-15 dB)
Quality factor (Q): 1.3 (wide) and 0.5 (narrow)
Middle Band (Peak Filter): 150 Hz - 3.5 kHz (+/-15 dB)
Quality factor (Q): 1.3 (wide) and 0.5 (narrow)
Top Band (Peak Filter): 700 Hz - 16 kHz (+/-15 dB)
Quality factor (Q): 1.3 (wide) and 0.5 (narrow)
High Band (Shelf Filter): 1.8 - 35 kHz (+/-15 dB)
High Band (Cut Filter): 1.8 - 35 kHz
THD+N @ 0 dBu, 20 Hz - 22 kHz: 0.0037 %
THD+N @ +10 dBu, 20 Hz - 22 kHz: 0.0038 %
Noise oor, 20 Hz - 20 kHz (A-weighted): -91.6 dBu
Dynamic range, 20 Hz - 22 kHz: 119 dB
Maximum input level: +27 dBu
Maximum output level: +27 dBu
Input impedance: 10 kOhm
Output impedance: 68 Ohm
Input pin assignment: 1. Ground
2. Positive
3. Negative
Output pin assignment: 1. Ground
2. Positive
3. With 68 Ohm to Ground
Power consumption: 60 W
Fuse type: 230 VAC 0.8 A Slo-Blo
115 VAC 1.6 A Slo-Blo
Dimensions (W x H x D): 483 mm x 89 mm x 377 mm
19 “ x 3.5“ (2 U) x 14.8“
Weight: 8 kg / 17.5 lb
