EM TEST UCS 500 Series
Operating Manual V 3.05 11 / 57
4.4. Service
SERVICE
F1 : Addresses
F3 : Set-up
F4 : Change standard levels
F7 : Status
F1 F2 F3 F4 F5 F6 F7
F1 Addresses
The addresses of the EM TEST AG and the EM TEST GmbH are shown. For all other addresses of all EM TEST
sales partners refer to
the URL www.emtest.com.
F3 Set-up
The software will clearly explain the set-up procedure.
F4 Change standard levels
F1: Set all parameters acc to standard The stored standard test levels can be changed within this menu.
The settings are actualised to the standards dated in summer 2004.
F2: IEC 61000-4
F1: IEC 61000-4-4 Burst
F2: IEC 61000-4-5 Surge
F3: IEC 61000-4-8 Magnetic field AC
F4: IEC 61000-4-9 Magnetic field Surge
F5: IEC 61000-4-11 Power Fail AC
F6: IEC 61000-4-29 Power Fail DC
F7: IEC 61000-4-2 ESD
F3: EN 61000-6-1 Generic
F1: EN 61000-6-1 Generic Burst
F2: EN 61000-6-1 Generic Surge
F3: EN 61000-6-1 Generic Power Fail
F4: EN 61000-6-2 Generic
F1: EN 61000-6-1 Generic Burst
F2: EN 61000-6-1 Generic Surge
F3: EN 61000-6-1 Generic Power Fail
F7 Status
Status information of the equipment.
Page 1 Page 2
UCS Model Built in modules Status Keyboard - Beep RS 232 Baudrate
Firmware Version
Status ESD - Beep IEEE Address
Firmware Number
Status Backlighting
Option Burst
Operating time DI – Status 00000 Voltage Magnetic field values
Device powered on
SCR-Status 00000
V : max ext. Variac Cf :Coil factor
Testing time
Vn : Nominal voltage Tf :Transformer factor
Device test time 2/2 Ch : Default channel If : Impedance factor
To Next Page
