6.2. SURGE Immunity requirements as per IEC 61000-4-5
Test level M4, UCS 500 upgrade M6/M6A
Open circuit voltage 160V - 4000V ± 10% 250V - 6600V ± 10%
Wave shape
Rise time tr 1,0 ± 30% 1,0 ± 30%
Pulse duration
50µs ± 20% 50µs ± 20%
Short circuit current 80A - 2000A ± 10% 125A - 3300A ± 10%
Wave shape
Rise time tr 6.4 ± 20% 6.4 ± 20%
Pulse duration
16µs ± 20% 16µs ± 20%
Polarity Pos., Neg., Alt Pos., Neg., Alt
Repetition rate max. 1Hz (1s* - 999s) max. 0.5Hz (2s* - 999s)
Events preselection 1 - 30'000 or endless 1 - 30'000 or endless
Counter 1 - 1000000 1 - 1000000
Trigger
Trigger of pulses AUTO, MAN, EXTERN AUTO, MAN, EXTERN
Synchronization 0 - 360° 0 - 360°
Resolution 1° 1°
Measurements
CRO 5V Trigger 5V Trigger
CRO Û 10Vp at 4kV 10Vp at 6.6kV
CRO Î 10Vp at 2kA 10Vp at 3.3kA
Peak voltmeter 4000V 6600V
Peak current meter 2000A 3300A
Output M4 M6 M6A
Direct
HV-coaxial connector; Zi = 2Ω
X
HV-Banana connector, Zi = 2Ω
X X
Coupling network
L – N with Z = 2Ω
X X X
L-PE, N-PE, L+N-PE with Z = 12Ω
X X X
L-PE, N-PE, L+N-PE with Z = 2Ω
X
DUT supply AC 250V / 16A / 50/60 Hz X X X
DC 250V / 10A X X X
Test routines
Quick Start
Immediate start, all parameters adjustable during a running test
Standard test routines as per IEC 61000-4-5 level 1
IEC 61000-4-5 level 2
IEC 61000-4-5 level 3
IEC 61000-4-5 level 4
EN 61000-6-1 Generic
EN 61000-6-2 Generic
IEC 61000-4-5 Manual operated standard routine
User test routines Change polarity after n pulses
Change coupling mode after n pulses
Change voltage level V after n pulses by ∆V
Change phase angle A after n pulses by ∆A
Magnetic field test test routine as per IEC 61000-4-9
test level 100, 300 and 1000A/m
cont. adjustable within Quick Start
