EM TEST UCS 500 Series
Operating Manual V 3.05 22 / 57
9.1.2. Standard test routines
The user can select preprogrammed standard test routines.
Page 2
Burst Standard test routines
F1 : IEC 61000-4-4 Level 1 500V
F2 : IEC 61000-4-4 Level 2 1000V
F3 : IEC 61000-4-4 Level 3 2000V
F4 : IEC 61000-4-4 Level 4 4000V
F5 : EN 61000-6-1 Generic 1000V
F6 : EN 61000-6-2 Generic 2000V
F7 : Manual test routine
F1 F2 F3 F4 F5 F6 F7
Page 3 (Show parameters and start the test)
Burst IEC 61000-4-4 Level 3
V = 2000 V f = 100 kHz
kop = COM T : 00:01 min 99:59 min
f : 5.0 kHz100 kHz
cpl : COM / ALL
T f cpl
START CHANGE 1:00 100 COM
F1 F2 F3 F4 F5 F6 F7 F1 F2 F3 F4 F5 F6 F7
The function „Change“ enables the operator to switch between 5kHz/100kHz spike frequency. The burst duration
will be automatically matched to 15ms respectively 0.75ms.
The coupling mode can be setted depends the Standard version ( ALL 1994 / COM 2004 )
Additionally the operator can enter the required test time.
Manual standard test routine
Burst Standard routine IEC 61000-4-4
<- -> O
Level 3 + 2000V L N 5.0 kHz
Testtime 0:00:45 h
START + /- L N PE L N PE f
F1 F2 F3 F4 F5 F6 F7
Within this test routine all standard parameters can be changed online during testing. This procedure therefore is
very easy and fast to use.
By pressing the function „f“ the operator can select between 5kHz and 100kHz spike frequency. The burst
duration will be automatically matched to 15ms respectively 0.75ms.
Example:
- By pushing the cursor ←→ the test level will be increased/decreased to the next standard level.
- By turning the INC knob (o) the test level can be continuously adjusted.
- Pressing the function keys the related function will be immediately activated.
- The displayed time will be resetted to zero after every new setting.
All functions can be operated during the running test.
