6. Display Timing
6-1. Applicable Video Timing
The following table lists the display quality modes that the LCD monitor provides. If the other
video modes are input, the monitor may not work or will display unsatisfactory picture
quality.
VESA MODES
Mode Resolution
Horizontal
Nominal
Frequency
+/- 1 kHz
Vertical
Nominal
Frequency
+/- 1 Hz
DOS 720*400@70Hz 31.469 70.087
640*480@60Hz 31.469 59.940
640*480@72Hz 37.861 72.809
VGA
640*480@75Hz 37.500 75.000
800*600@56Hz 35.156 56.250
800*600@60Hz 37.879 60.017
800*600@72Hz 48.077 72.188
SVGA
800*600@75Hz 46.875 75.000
1024*768@60Hz 48.363 60.004
1024*768@70Hz 56.476 70.069
XGA
1024*768@75Hz 60.023 75.029
Table 6.1 Applicable Video Timing
10 ENGLISH
6. Display Timing
IBM MODES
Mode Resolution
Horizontal
Nominal
Frequency
+/- 1 kHz
Vertical
Nominal
Frequency
+/- 1 Hz
EGA 640*350@70Hz 31.469 70.086
DOS 720*400@70Hz 31.469 70.087
VGA 640*480@60Hz 31.469 59.940
XGA 1024*768@72Hz 57.515 71.9
MAC MODES
VGA 640*480@60Hz 35.000 66.667
SVGA 832*624@75Hz 49.725 74.551
XGA 1024*768@75Hz 60.241 74.927
Table 6.2 Applicable Video Timing
