11
GX600 CYLINDER PARTS LIST
DESCRIPTION
COMPLETE CYL
PART #
BARREL
[1]
CYLINDER ROD
[3]
CYL. GLAND
[5]
PISTON
[12]
SHAFT NUT
[13]
SEAL KIT
BUTT END BUSH-
INGS [2]
ROD END BUSH-
INGS [4]
MAIN BOOM CYL 2 1/2" B13110 ORDER COMPLETE CYL B13421 B13422 B13423 B13424 B13415 B13313 [1] B13314 [2]
DIPPER CYL. 2" B13106 ORDER COMPLETE CYL B13425 B13426 B13427 B13424 B13414 B13314 [2] B13314 [2]
BUCKET CYL. 2" B13104 ORDER COMPLETE CYL B13428 B13426 B13427 B13424 B13414 B13314 [2] B13313 [1]
SWING CYL RH 2" B13113 ORDER COMPLETE CYL B13429 B13426 B13427 B13424 B13414 B13311 [2] (PIVOT) B13312 [2]
SWING CYL LH 2" B13114 ORDER COMPLETE CYL B13429 B13426 B13427 B13424 B13414 B13311 [2] (PIVOT) B13312 [2]
STABILIZER CYL. RH 2" B13117 ORDER COMPLETE CYL B13430 B13426 B13427 B13424 B13414 N/R N/R
STABILIZER CYL. LH 2" B13118 ORDER COMPLETE CYL B13430 B13426 B13427 B13424 B13414 N/R N/R
GX700 CYLINDER PARTS LIST
DESCRIPTION COMPLETE CYL
PART #
BARREL
[1]
CYLINDER ROD
[3]
CYL. GLAND
[5]
PISTON
[12]
SHAFT NUT
[13]
SEAL KIT BUTT END BUSH-
INGS [2]
ROD END BUSH-
INGS [4]
MAIN BOOM CYL 2 1/2" B13030 ORDER COMPLETE CYL B13431 B13422 B13423 B13424 B13415 B13313 [1] B13314 [2]
DIPPER CYL. 2 1/2" B13023 ORDER COMPLETE CYL B13432 B13422 B13423 B13424 B13415 B13314 [2] B13314 [2]
BUCKET CYL. 2 1/2" B13016 ORDER COMPLETE CYL B13433 B13422 B13423 B13424 B13415 B13314 [2] B13313 [1]
SWING CYL RH 2 1/2" B13038 ORDER COMPLETE CYL B13434 B13422 B13423 B13424 B13415 B13311 [2] (PIVOT) B13312 [2]
SWING CYL LH 2 1/2" B13039 ORDER COMPLETE CYL B13434 B13422 B13423 B13424 B13415 B13311 [2] (PIVOT) B13312 [2]
STABILIZER CYL. RH 2 1/2" B13043 ORDER COMPLETE CYL B13436 B13422 B13423 B13424 B13415 N/R N/R
STABILIZER CYL. LH 2 1/2" B13044 ORDER COMPLETE CYL B13436 B13422 B13423 B13424 B13415 N/R N/R
GX900 CYLINDER PARTS LIST
DESCRIPTION COMPLETE CYL
PART #
BARREL
[1]
CYLINDER ROD
[3]
CYL. GLAND
[5]
PISTON
[12]
SHAFT NUT
[13]
SEAL KIT BUTT END BUSH-
INGS [2]
ROD END BUSH-
INGS [4]
MAIN BOOM CYL 3" B13031 ORDER COMPLETE CYL B13438 B13440 B13441 B13424 B13416 B13313 [1] B13314 [2]
DIPPER CYL. 2 1/2" B13057 ORDER COMPLETE CYL B13439 B13422 B13423 B13424 B13415 B13314 [2] B13314 [2]
BUCKET CYL. 2 1/2" B13016 ORDER COMPLETE CYL B13433 B13422 B13423 B13424 B13415 B13314 [2] B13313 [1]
SWING CYL RH 2 1/2" B13038 ORDER COMPLETE CYL B13434 B13422 B13423 B13424 B13415 B13311 [2] (PIVOT) B13312 [2]
SWING CYL LH 2 1/2" B13039 ORDER COMPLETE CYL B13434 B13422 B13423 B13424 B13415 B13311 [2] (PIVOT) B13312 [2]
STABILIZER CYL. RH 2 1/2" B13043 ORDER COMPLETE CYL B13436 B13422 B13423 B13424 B13415 N/R N/R
STABILIZER CYL. LH 2 1/2" B13044 ORDER COMPLETE CYL B13436 B13422 B13423 B13424 B13415 N/R N/R
CYLINDER PARTS LIST
