Embed SmartTouch Swipe - Game Credit Connections

www.embedcard.com 10
If +12 v DC is not available from the game or is unstable then you will need to install a dedicated
+12v DC 1000mA supply. Note: it’s very important the DC Ground of the new power supply is
commoned with the existing DC Ground of the existing in game power supply. Without this
common ground ant ticket or coin monitoring will not operate correctly.
Game Credit Connections
Pin number
Wire Colour
Wire Function
7
ORANGE/BLACK
CREDIT 1 N.O.
8
YELLOW/BLACK
CREDIT 1 COM.
Note “N.O. means “Normally Open”, “COM.” Means “Common”
On the selected player station you can typically disconnect the common and normally open
connectors from the existing coin switch and plug them directly into the pre fitted harness
connectors.
Connect the other end of the harness to the smartTouch Swipe at connector J7.
