LOADING
AIRPLANE
OPERATIONS
MANUAL
1-07-30
Page
2
Code
44
REVISION 37
AOM-145/1114
EMB-145 CONFIGURATION OPTION 4
SEATS
ROW
PASSENGER
SEATS
BALANCE ARM
(m) (in)
1 - - -
2 2 7.111 279.96
3 3,4,5 7.898 310.98
4 6,7,8 8.686 341.97
5 9,10,11 9.473 372.99
6 12,13,14 10.261 403.98
7 15,16,17 11.048 434.96
8 18,19,20 11.835 465.98
9 21,22,23 12.623 496.97
10 24,25,26 13.410 527.99
11 27,28,29 14.198 558.98
12 30,31,32 15.163 596.97
13 33,34,35 15.950 627.99
14 36,37,38 16.738 658.98
15 39,40,41 17.525 689.96
16 42,43,44 18.312 720.98
17 45,46,47 19.100 751.97
18 48,49,50 19.887 782.99
Balance Arm
m (in)
Volume
m
3
(cu.ft)
Capacity
kg (lb)
WARDROBE
5.78 (227.48) 0.57 (20.2) 57 (126) **
FWD GALLEY
4.90 (192.91) * 82 (181) **
MID GALLEY
5.53 (217.72) * 113 (249) **
AFT GALLEY
6.79 (267.32) * 149 (328) **
* Total Galley Volume: 2.42 m
3
(85.4 cu.ft) / 6 half trolleys.
** Reference values. Check aircraft placards for actual values.
