LOADING
AIRPLANE
OPERATIONS
MANUAL
1-07-30
Page
2
Code
45
REVISION 38
AOM-145/1114
EMB-145 CONFIGURATION OPTION 5
SEATS
ROW
PASSENGER
SEATS
BALANCE ARM
(m) (in)
1 - - -
2 - - -
3 3,4,5 7.898 310.98
4 6,7,8 8.685 341.97
5 9,10,11 9.473 372.99
6 12,13,14 10.260 403.98
7 15,16,17 11.048 434.96
8 18,19,20 11.835 465.98
9 21,22,23 12.622 496.97
10 24,25,26 13.410 527.99
11 27,28,29 14.197 558.98
12 30,31,32 15.162 596.97
13 33,34,35 15.950 627.99
14 36,37,38 16.737 658.98
15 39,40,41 17.525 689.96
16 42,43,44 18.312 720.98
17 45,46,47 19.099 751.97
18 48,49,50 19.887 782.99
Balance Arm
m (in)
Volume
m
3
(cu.ft)
Capacity
kg (lb)
WARDROBE
6.153 (242.24) 1.07 (37.6) 80 (176) **
FWD GALLEY
4.90 (192.91) * 82 (181) **
MID GALLEY
5.53 (217.72) * 113 (249) **
AFT GALLEY
6.79 (267.32) * 149 (328) **
* Total Galley Volume: 2.42 m
3
(85.4 cu.ft)/6 half trolleys.
** Reference values. Check airplane placards for actual values.
