Embraer EMB145 - Page 1023

LOADING
AIRPLANE
OPERATIONS
MANUAL
1-07-30
Page
2
Code
49
REVISION 26
EMB-145 BAF SHUTTLE CONFIGURATION
SEATS
ROW
PASSENGER
SEATS
BALANCE ARM
(m) (in)
1 1 6.980 274.80
2 2,3,4 7.768 305.83
3 5,6,7 8.555 336.81
4 8,9,10 9.343 367.83
5 11,12,13 10.130 398.82
6 14, 15,16 10.917 429.80
7 17, 18,19 11.705 460.83
8 20, 21,22 12.492 491.81
9 23,24,25 13.280 522.83
10 26, 27,28 14.067 553.82
11 29,30,31 15.083 593.82
12 32, 33,34 15.870 624.80
13 35, 36,37 16.658 655.83
14 38, 39,40 17.445 686.81
15 41, 42,43 18.233 717.84
16 44, 45,46 19.020 748.82
17 47, 48,49 19.807 779.80
PASSENGER AVERAGE CG: 13.374 m / 526.524 in
Balance Arm
m (in)
Volume
m
3
(cu.ft)
Capacity
Kg (lb)
FWD GALLEY
5.55 (218.50) 0.085 (3.0)
184 (405)
*
WARDROBE
5.76 (226.77) 0.490 (17.30) 45 (99.2)
* Reference values. Check aircraft placards for actual values.
