Embraer EMB145 - Page 1025

LOADING
AIRPLANE
OPERATIONS
MANUAL
1-07-30
Page
2
Code
50
REVISON 26
EMB-145 BAF MEDEVAC CONFIGURATION
SEATS
ROW
PASSENGER
SEATS
BALANCE ARM
(m) (in)
1 1, 2, 3 13.280 522.83
2 4, 5, 6 14.067 553.82
3 7, 8, 9 15.083 593.82
4 10, 11, 12 15.870 624.80
5 13, 14, 15 16.658 655.83
6 16, 17, 18 17.445 686.81
7 19, 20, 21 18.233 717.84
8 22, 23, 24 19.020 748.82
9 25, 26, 27 19.807 779.80
PASSENGER AVERAGE CG: 16.607 m / 653.819 in
STRETCHER
BALANCE ARM
(m) (in)
E 8.235 324.21
F 10.673 420.20
G 10.673 420.20
Balance Arm
m (in)
Volume
m
3
(cu.ft)
Capacity
Kg (lb)
FWD GALLEY
5.55 (218.50) 0.085 (3.0)
184 (405)
*
WARDROBE
5.76 (226.77) 0.490 (17.30) 45 (99.2)
* Reference values. Check aircraft placards for actual values.
