Embraer EMB145 - Page 1057

LOADING
AIRPLANE
OPERATIONS
MANUAL
1-07-70
Page
4
Code
01
REVISION 37
AOM-145/1114
Balance Arm for each Section (*) - m (in)
EMB-145 ERJ-140 EMB-135
Forward Section
21.38
(841.54).
19.96
(785.82)
17.82
(701.57)
Central Section
22.515
(886.42)
21.095
(830.51)
18.965
(746.65)
Aft Section
23.78
(936.22)
22.36
(880.31)
20.23
(796.46)
EMB-145 Compartment Limits:
Baggage Compartment Available Volume................. 9.2 m
3
(325 cu.ft)
Maximum Floor Distributed Load..........................390 kg/m
2
(80 lb/ft2)
Total Maximum Capacity .........................................1200 kg (2646 lb)
Maximum Capacity per Section (*) ............................400 kg (882 lb)
ERJ-140 Compartment Limits:
Baggage Compartment Available Volume................. 9.2 m
3
(325 cu.ft)
Maximum Floor Distributed Load..........................390 kg/m
2
(80 lb/ft2)
Total Maximum Capacity .........................................1200 kg (2646 lb)
Maximum Capacity per Section (*) ............................400 kg (882 lb)
EMB-135 Compartment Limits:
Baggage Compartment Available Volume................. 9.2 m
3
(325 cu.ft)
Maximum Floor Distributed Load..........................390 kg/m
2
(80 lb/ft2)
Total Maximum Capacity .........................................1000 kg (2205 lb)
Maximum Capacity per Section (*) ............................333 kg (735 lb)
* - For airplanes with the optional Cargo Barrier Nets (vertical nets)
installed.
