Embraer EMB145 - Page 1096

AIRPLANE
OPERATIONS
MANUAL
CONFIGURATION
DEVIATION
LIST
REVISION 40
1-08-23
Page
1
Code
02
AOM-145/1114
ATA CHAPTER 23 COMMUNICATIONS
System & 1. 2. Number installed
Sequence ITEM 3. Number required for dispatch
Number 4. Remarks and/or exceptions
23 COMMUNICATIONS
60-1 Static Dischargers
(Figure 7)
(All except EMB-145XR)
22 13 A maximum of 9 (nine) static
dischargers may be missing
with no penalty. At least the
following dischargers are
required to be installed:
a) 3 (three) are installed on
each wing;
b) 1 (one) is installed on the
rudder;
c) 3 (three) are installed on
each elevator.
60-2 Static Dischargers
(Figure 7)
(EMB-145 XR)
26 17 A maximum of 9 (nine) static
dischargers may be missing
with no penalty. At least the
following dischargers are
required to be installed:
a) 4 (four) are installed on
each wing;
b) 1 (one) is installed on the
rudder:
c) 3 (three) are installed on
each elevator.
