AIRPLANE
OPERATIONS
MANUAL
CONFIGURATION
DEVIATION
LIST
REVISION 27
1-08-57
Page
1
Code
01
ATA CHAPTER 57 WINGS
System & 1. 2. Number installed
Sequence ITEM 3. Number required for dispatch
Number 4. Remarks and/or exceptions
57 WINGS
20-1 Vortex Generator
(Figure 27)
24 22 A maximum of 1 per wing
for a total of 2 may be
missing with no penalty.
30-2 Wing Tip Glareshield
(Figure 28)
2 0 May be missing with no
penalty.
42-1 Wing Grounding Point
(Figure 29)
2 0 One or both may be missing
with no penalty provided:
a) The hole is covered with
Scotch Brand Tape
(Silver Tape) or similar
product and,
b) The landing gear
grounding point is
available.
52-1 Flap Track Fairing
(Figure 30)
10 9 One may be missing with no
penalty.
52-2 Wing-to-flap seal
(Figure 31)
4 3 One may be missing
provided maximum airspeed
is limited to 250 KIAS /
M0.65, whichever is lower.
