Embraer EMB145 - Page 1246

AIRPLANE
OPERATIONS
MANUAL
GROUND SERVICING
REVISION 39
1-12-10
Page
11
Code
01
AOM-145/1114
HAZARD AREAS
EM145AOM121006A.DGN
10°
ENGINE INLET
INGESTION
HAZARD AREA
APU
HAZARD AREA
ENGINE EXHAUST
HAZARD AREA
4.3 m
7 m
3 m
9 ft−10 in
3 m
9 ft−10 in
2 m
8 m
3.6 m
30 m
6 ft−7 in
26 ft−3 in
11 ft−10 in
14 ft−1 in 98 ft−5 in22 ft−12 in
30 m
98 ft−5 in
10°
8 m
3.6 m
26 ft−3 in
11 ft−10 in
3 m
9 ft−10 in
3 m
9 ft−10 in
2 m
6 ft−7 in
4.3 m
14 ft−1 in
6 m
19 ft−8 in
ENGINE INLET
INGESTION
HAZARD AREA
APU
HAZARD AREA
ENGINE EXHAUST
HAZARD AREA
(*) ENGINE
ACCESSORIES
CAUTION AREA
(*) ENGINE
ACCESSORIES
CAUTION AREA
EMB−145 MODEL
EMB−135 MODEL
(*) Access to this area is permitted just with engine running in idle
speed.
