GROUND SERVICING
AIRPLANE
OPERATIONS
MANUAL
1-12-15
Page
4
Code
01
APRIL 28, 2000
The following table gives the surface conditions and wind velocities at
which mooring is necessary;
Wind Limitation Table
Surface Condition Wind Velocity
Ice 25 Kt
Snow 40 Kt
Wet Concrete 55 Kt
Dry Concrete 60 Kt
To moor the aircraft, proceed as follows:
− Tow the aircraft to a parking area where there are tiedown anchors
available.
− Carry out the normal parking procedure.
− Install the tiedown rings (two), one in each primary brace strut of the
main landing gear.
− Attach a nylon rope to the tiedown ring with a bowline knot, and
then attach the other end of the rope to the tiedown anchor on the
ground by knotting it with a bowline knot. See the corresponding
illustration on the previous page.
