VIDEO SYSTEM CONTROL UNIT (VSCU)
The VSCU is responsible for collecting Video signals from the DVD
Player, Video Cassette Player and Airshow, and Audio signals from
the DVD Player, CD Player, Video Cassette Player and Airshow.
1 - VSCU DISPLAY
Shows the video and audio channels to be selected and
displayed on the forward galley preview monitor and heard on
the headphone connected to the VSCU Panel headphone jack.
2 - POWER KEY BUTTON
When pressed, turns on the VSCU.
3 - SELECT RIGHT KEY
Selects the subsequent channel to be displayed on the preview
monitor.
4 - VOLUME UP KEY
Increases the volume on the headphone.
5 - ENTER KEY
Selects the video signal that will be displayed on passenger
monitors, and which audio signal will be sent to passenger
loudspeakers.
6 - HEADPHONE JACK
To connect a headphone and allow the flight attendant to hear
the audio signal associated with the video displayed on the
preview monitor.
7 - VOLUME DOWN KEY
Decreases the volume on the headphone.
8 - SELECT LEFT KEY
− Selects the previous channels to be displayed on the preview
monitor
