DISPLAYS CONTROL PANEL
NOTE: For further information on displays control panel, refer to
Sections 2-17 – Flight Instruments and 2-18 – Navigation and
Communication .
1 - TEST BUTTON
− On the ground:
− When pressed, activates the IC-600s first level test.
− When pressed for more than 6 seconds activates the
IC 600s second level test.
− When released, normal operation of IC-600s is resumed.
− In flight:
Refer to Radio Altimeter description on Section 2-17 – Flight
Instruments.
DISPLAYS CONTROL PANEL
