The PFD first level test indications are as follows:
− A magenta TEST is displayed in upper left center of the PFD.
− Indications removed: all bugs, flight director information, all
pointers, low airspeed awareness, take-off speed bugs and digital
readouts, V
MO
/M
MO
, and trend vectors.
− Indications forced: all comparison monitors, all marker beacons,
and windshear annunciation.
− Indications presented as invalid: pitch and roll, vertical and lateral
deviations, baro correction, vertical speed set digital readout,
altitude preselect, heading, distance digital readout, ground speed
(or time to go or elapsed time), selected heading and course (or
desired track), Mach, airspeed, airspeed set digital readout, altitude.
− If heading is valid upon test activation, its source annunciation will
remain valid (DG1 or 2 or MAG1 or 2). If heading is invalid, its
source annunciation will change to HDG1 or HDG2.
